1-1/2" Cut Dia, 3/4" Arbor Hole Dia, 5.5mm Max Depth, Indexable Square-Shoulder Face Mill

1-1/2″ Cut Dia, 3/4″ Arbor Hole Dia, 5.5mm Max Depth, Indexable Square-Shoulder Face Mill

130,99 $

SKU: SKUV5MbmaW8zk Categories: Indexable Cutting Tools, Indexable Milling, Shop All Products Tag: Sandvik Coromant Brand: Sandvik Coromant

Description
Reviews (0)

Specifications

Maximum Cutting Diameter (Inch): 1-1/2	Maximum Depth of Cut (mm): 5.50
Maximum Depth of Cut (Decimal Inch): 0.2165	Arbor Hole Diameter (Inch): 3/4
Arbor Hole Diameter (Decimal Inch): 0.7500	Compatible Insert Size Code: 490R-08T308
Cutter Style: A490..Rxx	Cutting Direction: Right Hand
Insert Holding Method: Screw; Clamp	Lead Angle: 90
Series: CoroMill 490	UNSPSC Code: 27112803
Toolholder Material: Steel	Coolant Through: Yes
Number Of Cutter Inserts: 5	Number Of Flutes: 5
Country of Origin: UNITED STATES
Maximum Cutting Diameter (Inch): 1-1/2
Maximum Depth of Cut (mm): 5.50
Maximum Depth of Cut (Decimal Inch): 0.2165
Arbor Hole Diameter (Inch): 3/4
Arbor Hole Diameter (Decimal Inch): 0.7500
Compatible Insert Size Code: 490R-08T308
Cutter Style: A490..Rxx
Cutting Direction: Right Hand
Insert Holding Method: Screw; Clamp
Lead Angle: 90
Series: CoroMill 490
UNSPSC Code: 27112803
Toolholder Material: Steel
Coolant Through: Yes
Number Of Cutter Inserts: 5
Number Of Flutes: 5
Country of Origin: UNITED STATES
