Ball End Mill: 1/32″ Dia, 1/16″ LOC, 4 Flute, Solid Carbide

Name: Ball End Mill: 1/32" Dia, 1/16" LOC, 4 Flute, Solid Carbide - Industrial Tool
Price: 10.99 USD
Availability: InStock

10,99 $

Shop Ball End Mill: 1/32″ Dia, 1/16″ LOC, 4 Flute, Solid Carbide at MSC Direct top provider of high quality products

Specifications

Mill Diameter (Decimal Inch): 0.0313	Mill Diameter (Inch): 1/32
Number Of Flutes: 4	End Mill Material: Solid Carbide
Length of Cut (Decimal Inch): 0.0625	Length of Cut (Inch): 1/16
Shank Diameter (Inch): 1/8	Overall Length (Inch): 1-1/2
Single Or Double End: Single	Coating/Finish Family: Bright/Uncoated
Centercutting: Yes	Cutting Direction: Right Hand
Flute Direction: Right Hand	Extended Reach: No
Coolant Through: No	Helix Angle: 30
Coating/Finish: Bright/Uncoated	Variable Helix: No
Variable Index: No	Chipbreaker: No
Flute Type: Spiral	Series: HBSC4-CC
System Of Measurement: Fractional Inch	UNSPSC Code: 27112803
Country of Origin: South Korea
Mill Diameter (Decimal Inch): 0.0313
Mill Diameter (Inch): 1/32
Number Of Flutes: 4
End Mill Material: Solid Carbide
Length of Cut (Decimal Inch): 0.0625
Length of Cut (Inch): 1/16
Shank Diameter (Inch): 1/8
Overall Length (Inch): 1-1/2
Single Or Double End: Single
Coating/Finish Family: Bright/Uncoated
Centercutting: Yes
Cutting Direction: Right Hand
Flute Direction: Right Hand
Extended Reach: No
Coolant Through: No
Helix Angle: 30
Coating/Finish: Bright/Uncoated
Variable Helix: No
Variable Index: No
Chipbreaker: No
Flute Type: Spiral
Series: HBSC4-CC
System Of Measurement: Fractional Inch
UNSPSC Code: 27112803
Country of Origin: South Korea
