Indexable Ball Nose End Mill: 5/8" Cut Dia, 1.87" OAL

Indexable Ball Nose End Mill: 5/8″ Cut Dia, 1.87″ OAL

124,89 $

SKU: SKUhFoWb3AnfQ Categories: Indexable Cutting Tools, Indexable Milling, Shop All Products Tag: Iscar Brand: Iscar

Description
Reviews (0)

Specifications

Cutting Diameter (Decimal Inch): 0.6250	Shank Type: Modular Connection
Shank Diameter (Decimal Inch): 0.5670	Shank Diameter (mm): 14.40
Insert Holding Method: Screw	Modular Connection Thread Size: M08
Compatible Insert Style: HCD-QF; HCR; HBF-QF; HBR-QF	Toolholder Style: HCM-M
Tapered Neck: No	Overall Length (Decimal Inch): 1.8700
Series: BallPlus; FlexFit	Head Length (Decimal Inch): 1.1810
Tool Application: Milling	Standards: ISO 13399
Weldon Flat: No	Cutting Diameter (Inch): 5/8
Coolant Through: No	UNSPSC Code: 27112803
Product Service Code: 3417	Country of Origin: Israel
Cutting Diameter (Decimal Inch): 0.6250
Shank Type: Modular Connection
Shank Diameter (Decimal Inch): 0.5670
Shank Diameter (mm): 14.40
Insert Holding Method: Screw
Modular Connection Thread Size: M08
Compatible Insert Style: HCD-QF; HCR; HBF-QF; HBR-QF
Toolholder Style: HCM-M
Tapered Neck: No
Overall Length (Decimal Inch): 1.8700
Series: BallPlus; FlexFit
Head Length (Decimal Inch): 1.1810
Tool Application: Milling
Standards: ISO 13399
Weldon Flat: No
Cutting Diameter (Inch): 5/8
Coolant Through: No
UNSPSC Code: 27112803
Product Service Code: 3417
Country of Origin: Israel
