Indexable Boring Bar: A06M-STFCR2, 1/2″ Min Bore, Right Hand, 3/8″ Shank Dia, 0.000 deg Lead Angle, Steel
Original price was: 221,00 $.138,99 $Current price is: 138,99 $.
Specifications
| Minimum Bore Diameter (mm): 12.70 | Minimum Bore Diameter (Decimal Inch): 0.5000 |
| Minimum Bore Diameter (Inch): 1/2 | Toolholder Style: A-STFC |
| Tool Material: Steel | Insert Compatibility: TCMT 21.51 |
| Shank Diameter (mm): 9.53 | Shank Diameter (Inch): 3/8 |
| Hand of Holder: Right Hand | Overall Length (Decimal Inch): 6.0000 |
| Overall Length (mm): 152.40 | Overall Length (Inch): 6 |
| Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.5000 | Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.5000 |
| Insert Holding Method: Screw Clamping | Rake: Neutral |
| Rake Angle: 0.000 | Lead Angle: 0.000 |
| Series: CoroTurn 107 | Insert Inscribed Circle (Inch): 1/4 |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | Insert Inscribed Circle (mm): 6.35 |
| Multi-use Tool: Yes | Back of Bar to Cutting Edge (Decimal Inch): 6.0000 |
| Back of Bar to Cutting Edge (mm): 152.40 | Center to Cutting Edge (Decimal Inch): 0.2500 |
| Center to Cutting Edge (Inch): 1/4 | Center to Cutting Edge (mm): 6.35 |
| Number of Inserts Used on Toolholder: 1 | Neck Diameter (Decimal Inch): 0.3750 |
| UNSPSC Code: 23241601 | Neck Diameter (Inch): 3/8 |
| Insert Thickness (Decimal Inch): 0.0938 | Insert Thickness (Inch): 3/32 |
| Manufacturers Catalog Number: A06M-STFCR 2 | Coolant Through: Yes |
| Country of Origin: India | |
| Minimum Bore Diameter (mm): 12.70 | |
| Minimum Bore Diameter (Decimal Inch): 0.5000 | |
| Minimum Bore Diameter (Inch): 1/2 | |
| Toolholder Style: A-STFC | |
| Tool Material: Steel | |
| Insert Compatibility: TCMT 21.51 | |
| Shank Diameter (mm): 9.53 | |
| Shank Diameter (Inch): 3/8 | |
| Hand of Holder: Right Hand | |
| Overall Length (Decimal Inch): 6.0000 | |
| Overall Length (mm): 152.40 | |
| Overall Length (Inch): 6 | |
| Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.5000 | |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.5000 | |
| Insert Holding Method: Screw Clamping | |
| Rake: Neutral | |
| Rake Angle: 0.000 | |
| Lead Angle: 0.000 | |
| Series: CoroTurn 107 | |
| Insert Inscribed Circle (Inch): 1/4 | |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | |
| Insert Inscribed Circle (mm): 6.35 | |
| Multi-use Tool: Yes | |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | |
| Back of Bar to Cutting Edge (mm): 152.40 | |
| Center to Cutting Edge (Decimal Inch): 0.2500 | |
| Center to Cutting Edge (Inch): 1/4 | |
| Center to Cutting Edge (mm): 6.35 | |
| Number of Inserts Used on Toolholder: 1 | |
| Neck Diameter (Decimal Inch): 0.3750 | |
| UNSPSC Code: 23241601 | |
| Neck Diameter (Inch): 3/8 | |
| Insert Thickness (Decimal Inch): 0.0938 | |
| Insert Thickness (Inch): 3/32 | |
| Manufacturers Catalog Number: A06M-STFCR 2 | |
| Coolant Through: Yes | |
| Country of Origin: India |
| MSC# | 40705543 |
| Mfr# | 5937342 |
