Indexable Boring Bar: A08M-SDUCR2, 18.50 mm Min Bore, Right Hand, 12.70 mm Shank Dia, 0.000 deg Lead Angle, Steel
128,89 $
Specifications
| Minimum Bore Diameter (mm): 18.50 | Minimum Bore Diameter (Decimal Inch): 0.7283 |
| Toolholder Style: A-SDUC | Tool Material: Steel |
| Insert Compatibility: DCMT 21.51 | Shank Diameter (mm): 12.70 |
| Shank Diameter (Inch): 1/2 | Hand of Holder: Right Hand |
| Overall Length (Decimal Inch): 6.0000 | Overall Length (mm): 152.40 |
| Overall Length (Inch): 6 | Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.7283 |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.7283 | Insert Holding Method: Screw Clamping |
| Rake: Neutral | Rake Angle: 0.000 |
| Lead Angle: 0.000 | Series: CoroTurn 107 |
| Insert Inscribed Circle (Inch): 1/4 | Insert Inscribed Circle (Decimal Inch): 0.2500 |
| Insert Inscribed Circle (mm): 6.35 | Multi-use Tool: Yes |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | Back of Bar to Cutting Edge (mm): 152.40 |
| Center to Cutting Edge (Decimal Inch): 0.4380 | Center to Cutting Edge (mm): 11.13 |
| Number of Inserts Used on Toolholder: 1 | Neck Diameter (Decimal Inch): 0.5000 |
| UNSPSC Code: 23241601 | Neck Diameter (Inch): 1/2 |
| Insert Thickness (Decimal Inch): 0.0938 | Insert Thickness (Inch): 3/32 |
| Manufacturers Catalog Number: A08M-SDUCR 2 | Coolant Through: Yes |
| Country of Origin: India | |
| Minimum Bore Diameter (mm): 18.50 | |
| Minimum Bore Diameter (Decimal Inch): 0.7283 | |
| Toolholder Style: A-SDUC | |
| Tool Material: Steel | |
| Insert Compatibility: DCMT 21.51 | |
| Shank Diameter (mm): 12.70 | |
| Shank Diameter (Inch): 1/2 | |
| Hand of Holder: Right Hand | |
| Overall Length (Decimal Inch): 6.0000 | |
| Overall Length (mm): 152.40 | |
| Overall Length (Inch): 6 | |
| Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.7283 | |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.7283 | |
| Insert Holding Method: Screw Clamping | |
| Rake: Neutral | |
| Rake Angle: 0.000 | |
| Lead Angle: 0.000 | |
| Series: CoroTurn 107 | |
| Insert Inscribed Circle (Inch): 1/4 | |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | |
| Insert Inscribed Circle (mm): 6.35 | |
| Multi-use Tool: Yes | |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | |
| Back of Bar to Cutting Edge (mm): 152.40 | |
| Center to Cutting Edge (Decimal Inch): 0.4380 | |
| Center to Cutting Edge (mm): 11.13 | |
| Number of Inserts Used on Toolholder: 1 | |
| Neck Diameter (Decimal Inch): 0.5000 | |
| UNSPSC Code: 23241601 | |
| Neck Diameter (Inch): 1/2 | |
| Insert Thickness (Decimal Inch): 0.0938 | |
| Insert Thickness (Inch): 3/32 | |
| Manufacturers Catalog Number: A08M-SDUCR 2 | |
| Coolant Through: Yes | |
| Country of Origin: India |
| MSC# | 30044895 |
| Mfr# | 5721305 |
