Sale!
Indexable Boring Bar: E06M-SCLCR2-R, 12.20 mm Min Bore, Right Hand, 9.53 mm Shank Dia, 0.000 deg Lead Angle, Solid Carbide
Original price was: 528,00 $.130,99 $Current price is: 130,99 $.
Specifications
| Minimum Bore Diameter (mm): 12.20 | Minimum Bore Diameter (Decimal Inch): 0.4803 |
| Toolholder Style: E-SCLC | Tool Material: Solid Carbide |
| Insert Compatibility: CCMT 21.51 | Shank Diameter (mm): 9.53 |
| Shank Diameter (Inch): 3/8 | Hand of Holder: Right Hand |
| Overall Length (Decimal Inch): 6.0000 | Overall Length (mm): 152.40 |
| Overall Length (Inch): 6 | Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.4803 |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.4803 | Insert Holding Method: Screw Clamping |
| Rake: Neutral | Rake Angle: 0.000 |
| Lead Angle: 0.000 | Series: CoroTurn 107 |
| Insert Inscribed Circle (Inch): 1/4 | Insert Inscribed Circle (Decimal Inch): 0.2500 |
| Insert Inscribed Circle (mm): 6.35 | Multi-use Tool: Yes |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | Back of Bar to Cutting Edge (mm): 152.40 |
| Center to Cutting Edge (Decimal Inch): 0.2500 | Center to Cutting Edge (Inch): 1/4 |
| Center to Cutting Edge (mm): 6.35 | Number of Inserts Used on Toolholder: 1 |
| Neck Diameter (Decimal Inch): 0.3750 | UNSPSC Code: 23241601 |
| Neck Diameter (Inch): 3/8 | Insert Thickness (Decimal Inch): 0.0750 |
| Manufacturers Catalog Number: E06M-SCLCR 2-R | Coolant Through: Yes |
| Country of Origin: India | |
| Minimum Bore Diameter (mm): 12.20 | |
| Minimum Bore Diameter (Decimal Inch): 0.4803 | |
| Toolholder Style: E-SCLC | |
| Tool Material: Solid Carbide | |
| Insert Compatibility: CCMT 21.51 | |
| Shank Diameter (mm): 9.53 | |
| Shank Diameter (Inch): 3/8 | |
| Hand of Holder: Right Hand | |
| Overall Length (Decimal Inch): 6.0000 | |
| Overall Length (mm): 152.40 | |
| Overall Length (Inch): 6 | |
| Minimum Bore Diameter Using Triangle Insert Cartridge (Decimal Inch): 0.4803 | |
| Minimum Bore Diameter Using Diamond Insert Cartridge (Decimal Inch): 0.4803 | |
| Insert Holding Method: Screw Clamping | |
| Rake: Neutral | |
| Rake Angle: 0.000 | |
| Lead Angle: 0.000 | |
| Series: CoroTurn 107 | |
| Insert Inscribed Circle (Inch): 1/4 | |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | |
| Insert Inscribed Circle (mm): 6.35 | |
| Multi-use Tool: Yes | |
| Back of Bar to Cutting Edge (Decimal Inch): 6.0000 | |
| Back of Bar to Cutting Edge (mm): 152.40 | |
| Center to Cutting Edge (Decimal Inch): 0.2500 | |
| Center to Cutting Edge (Inch): 1/4 | |
| Center to Cutting Edge (mm): 6.35 | |
| Number of Inserts Used on Toolholder: 1 | |
| Neck Diameter (Decimal Inch): 0.3750 | |
| UNSPSC Code: 23241601 | |
| Neck Diameter (Inch): 3/8 | |
| Insert Thickness (Decimal Inch): 0.0750 | |
| Manufacturers Catalog Number: E06M-SCLCR 2-R | |
| Coolant Through: Yes | |
| Country of Origin: India |
| MSC# | 52077500 |
| Mfr# | 5853216 |
