Indexable Copy End Mill: 1-1/4 to 1-1/4″ Cut Dia, 0.248″ Max Depth of Cut, Through Coolant
Original price was: 583,00 $.128,89 $Current price is: 128,89 $.
Specifications
| Minimum Cutting Diameter (Inch): 1-1/4 | Minimum Cutting Diameter (Decimal Inch): 1.2500 |
| Minimum Cutting Diameter (mm): 0.75 | Cutting Diameter (Decimal Inch): 1.2500 |
| Maximum Cutting Diameter (Decimal Inch): 1.2500 | Maximum Cutting Diameter (Inch): 1-1/4 |
| Maximum Depth of Cut (Decimal Inch): 0.2480 | Maximum Depth of Cut (mm): 6.30 |
| Toolholder Style: RA300 | Shank Type: Cylindrical |
| Compatible Insert Style: R300-1340 | Insert Holding Method: Screw |
| Number Of Cutter Inserts: 2 | Overall Length (Inch): 6 |
| Overall Length (Decimal Inch): 6.0000 | Series: CoroMill® 300 |
| Shank Length (mm): 114.30 | Shank Length (Decimal Inch): 4.5000 |
| Head Length (Inch): 1-1/2 | Head Length (Decimal Inch): 1.5000 |
| Insert Diameter (mm): 13.00 | Toolholder Material: Steel |
| Weldon Flat: No | UNSPSC Code: 27112803 |
| ISO Number: RA300-032O32-13H | Cutting Diameter (Inch): 1-1/4 |
| Number Of Flutes: 2 | Coolant Through: Yes |
| Country of Origin: UNITED STATES | |
| Minimum Cutting Diameter (Inch): 1-1/4 | |
| Minimum Cutting Diameter (Decimal Inch): 1.2500 | |
| Minimum Cutting Diameter (mm): 0.75 | |
| Cutting Diameter (Decimal Inch): 1.2500 | |
| Maximum Cutting Diameter (Decimal Inch): 1.2500 | |
| Maximum Cutting Diameter (Inch): 1-1/4 | |
| Maximum Depth of Cut (Decimal Inch): 0.2480 | |
| Maximum Depth of Cut (mm): 6.30 | |
| Toolholder Style: RA300 | |
| Shank Type: Cylindrical | |
| Compatible Insert Style: R300-1340 | |
| Insert Holding Method: Screw | |
| Number Of Cutter Inserts: 2 | |
| Overall Length (Inch): 6 | |
| Overall Length (Decimal Inch): 6.0000 | |
| Series: CoroMill® 300 | |
| Shank Length (mm): 114.30 | |
| Shank Length (Decimal Inch): 4.5000 | |
| Head Length (Inch): 1-1/2 | |
| Head Length (Decimal Inch): 1.5000 | |
| Insert Diameter (mm): 13.00 | |
| Toolholder Material: Steel | |
| Weldon Flat: No | |
| UNSPSC Code: 27112803 | |
| ISO Number: RA300-032O32-13H | |
| Cutting Diameter (Inch): 1-1/4 | |
| Number Of Flutes: 2 | |
| Coolant Through: Yes | |
| Country of Origin: UNITED STATES |
| MSC# | 37056066 |
| Mfr# | 5739764 |
