Indexable Grooving Blade: 1.2559″ High, Neutral

Original price was: 422,00 $.Current price is: 128,89 $.

Specifications

Cutting Direction: Neutral	Blade Style: QD-NN2..C..A
Blade Height (mm): 31.90	Blade Height (Decimal Inch): 1.2559
Blade Width (Decimal Inch): 0.2200	Blade Width (mm): 5.67
Maximum Depth of Cut (Decimal Inch): 2.3622	Maximum Depth of Cut (mm): 60.00
Insert Holding Method: Clamp	Maximum Insert Width (mm): 5.68
Maximum Insert Width (Decimal Inch): 0.2236	Compatible Insert Style: QD-NN2..C..A
Series: CoroCut QD	Compatible Cartridge Size: 25
Cutting Tool Application: Parting	Blade Overall Length (mm): 150.00
Blade Overall Length (Decimal Inch): 5.9055	Manufacturers Catalog Number: 6397286
Insert Seat Size: K	Cartridge Size: 25
Complete Insert Compatibility: QD-NK-0600-0003-CM	Single Or Double End: Double
UNSPSC Code: 27112809	Country of Origin: Sweden
Cutting Direction: Neutral
Blade Style: QD-NN2..C..A
Blade Height (mm): 31.90
Blade Height (Decimal Inch): 1.2559
Blade Width (Decimal Inch): 0.2200
Blade Width (mm): 5.67
Maximum Depth of Cut (Decimal Inch): 2.3622
Maximum Depth of Cut (mm): 60.00
Insert Holding Method: Clamp
Maximum Insert Width (mm): 5.68
Maximum Insert Width (Decimal Inch): 0.2236
Compatible Insert Style: QD-NN2..C..A
Series: CoroCut QD
Compatible Cartridge Size: 25
Cutting Tool Application: Parting
Blade Overall Length (mm): 150.00
Blade Overall Length (Decimal Inch): 5.9055
Manufacturers Catalog Number: 6397286
Insert Seat Size: K
Cartridge Size: 25
Complete Insert Compatibility: QD-NK-0600-0003-CM
Single Or Double End: Double
UNSPSC Code: 27112809
Country of Origin: Sweden
