Indexable Grooving-Cutoff Toolholder: DGTR 25.4B-2D35, 0.075 to 0.098″ Groove Width, 0.689″ Max Depth of Cut, Right Hand
120,89 $
Specifications
| Internal or External: External | Hand of Holder: Right Hand |
| Maximum Depth of Cut (Decimal Inch): 0.6890 | Maximum Groove Width (Decimal Inch): 0.0980 |
| Minimum Groove Width (Decimal Inch): 0.0750 | Toolholder Style: DGT |
| Insert Holding Method: Clamp | Compatible Insert Size Code: DGR/L-J/JS; DGN/DGNM-J/JS/JT |
| Insert Compatibility: DGN | Shank Height (Decimal Inch): 1.0000 |
| Shank Length (Decimal Inch): 4.2000 | Shank Width/Diameter (Decimal Inch): 1.0000 |
| Shank Width/Diameter (Inch): 1 | Series: Do-Grip |
| Overall Length (Decimal Inch): 5.5000 | Cutting Tool Application: Grooving; Cut-Off |
| Full Radius Insert: No | Back of Bar to Cutting Edge (Decimal Inch): 0.9700 |
| Head Length (Decimal Inch): 1.3000 | Standards: ISO 13399 |
| Complete Insert Compatibility: DGN 1900WP; DGN 2002JT; DGN 2502C; DGN 2000P; DGN 2400WP; DGN 2202C; DGN 2002C; DGN 2200JS; DGN 2202JT; DGN 2202J; DGN 2202UA; DGN 2202UT | Coolant Through: No |
| UNSPSC Code: 23153308 | Country of Origin: Israel |
| Internal or External: External | |
| Hand of Holder: Right Hand | |
| Maximum Depth of Cut (Decimal Inch): 0.6890 | |
| Maximum Groove Width (Decimal Inch): 0.0980 | |
| Minimum Groove Width (Decimal Inch): 0.0750 | |
| Toolholder Style: DGT | |
| Insert Holding Method: Clamp | |
| Compatible Insert Size Code: DGR/L-J/JS; DGN/DGNM-J/JS/JT | |
| Insert Compatibility: DGN | |
| Shank Height (Decimal Inch): 1.0000 | |
| Shank Length (Decimal Inch): 4.2000 | |
| Shank Width/Diameter (Decimal Inch): 1.0000 | |
| Shank Width/Diameter (Inch): 1 | |
| Series: Do-Grip | |
| Overall Length (Decimal Inch): 5.5000 | |
| Cutting Tool Application: Grooving; Cut-Off | |
| Full Radius Insert: No | |
| Back of Bar to Cutting Edge (Decimal Inch): 0.9700 | |
| Head Length (Decimal Inch): 1.3000 | |
| Standards: ISO 13399 | |
| Complete Insert Compatibility: DGN 1900WP; DGN 2002JT; DGN 2502C; DGN 2000P; DGN 2400WP; DGN 2202C; DGN 2002C; DGN 2200JS; DGN 2202JT; DGN 2202J; DGN 2202UA; DGN 2202UT | |
| Coolant Through: No | |
| UNSPSC Code: 23153308 | |
| Country of Origin: Israel |
| MSC# | 52702008 |
| Mfr# | 2301427 |
