Indexable Grooving Toolholder: GEHIR15.9-20-3T8, Right Hand
Original price was: 280,00 $.138,99 $Current price is: 138,99 $.
Specifications
| Hand of Holder: Right Hand | Maximum Depth of Cut (Decimal Inch): 0.1570 |
| Minimum Groove Width (Decimal Inch): 0.0950 | Toolholder Style: GEHI |
| Maximum Groove Width (Decimal Inch): 0.1260 | Insert Holding Method: Clamp |
| Insert Compatibility: GEMI..; GEPI.. | Compatible Insert Size Code: GEPI-WT; GEPI; GEMI (Full Radius); GEMI; GEPI (Full Radius); GEPI-MT |
| Series: Cut Grip | Overall Length (Decimal Inch): 6.0000 |
| Multi-use Tool: No | Center to Cutting Edge (Decimal Inch): 0.6400 |
| Minimum Hole Diameter (Decimal Inch): 0.7870 | Primary Workpiece Material: Universal |
| UNSPSC Code: 23153308 | Primary Workpiece Material Code: P; S; H; K; M; N |
| Coolant Hole Diameter (mm): 6.00 | Maximum Bore Depth (Decimal Inch): 0.3150 |
| Complete Insert Compatibility: GEPI 2.5-WT0.05; GEPI 3.18-1.59; GEPI 3.00-1.50; GEMI 3002M; GEPI 2.50-0.10; GEPI 2.50-0.20; GEPI 2.70-0.20; GEPI 3.00-0.20; GEPI 2.47-0.20; GEPI 2.5-MT0.05 | MSC/Manufacturer Number: GEHIR/L 15.9-20-3-T8 |
| Coolant Through: Yes | Country of Origin: Israel |
| Hand of Holder: Right Hand | |
| Maximum Depth of Cut (Decimal Inch): 0.1570 | |
| Minimum Groove Width (Decimal Inch): 0.0950 | |
| Toolholder Style: GEHI | |
| Maximum Groove Width (Decimal Inch): 0.1260 | |
| Insert Holding Method: Clamp | |
| Insert Compatibility: GEMI..; GEPI.. | |
| Compatible Insert Size Code: GEPI-WT; GEPI; GEMI (Full Radius); GEMI; GEPI (Full Radius); GEPI-MT | |
| Series: Cut Grip | |
| Overall Length (Decimal Inch): 6.0000 | |
| Multi-use Tool: No | |
| Center to Cutting Edge (Decimal Inch): 0.6400 | |
| Minimum Hole Diameter (Decimal Inch): 0.7870 | |
| Primary Workpiece Material: Universal | |
| UNSPSC Code: 23153308 | |
| Primary Workpiece Material Code: P; S; H; K; M; N | |
| Coolant Hole Diameter (mm): 6.00 | |
| Maximum Bore Depth (Decimal Inch): 0.3150 | |
| Complete Insert Compatibility: GEPI 2.5-WT0.05; GEPI 3.18-1.59; GEPI 3.00-1.50; GEMI 3002M; GEPI 2.50-0.10; GEPI 2.50-0.20; GEPI 2.70-0.20; GEPI 3.00-0.20; GEPI 2.47-0.20; GEPI 2.5-MT0.05 | |
| MSC/Manufacturer Number: GEHIR/L 15.9-20-3-T8 | |
| Coolant Through: Yes | |
| Country of Origin: Israel |
| MSC# | 60686169 |
| Mfr# | 2801780 |
| Big Book# | 889 |
