Indexable Grooving Toolholder: HELIR 19-3T20, External, Right Hand, 1.76″ Max Workpiece Dia
Original price was: 211,00 $.140,89 $Current price is: 140,89 $.
Specifications
| Toolholder Type: External Grooving | Hand of Holder: Right Hand |
| Minimum Groove Width (Decimal Inch): 0.1180 | Toolholder Style: HELI |
| Maximum Groove Width (Decimal Inch): 0.1250 | Maximum Groove Width (Inch): 1/8 |
| Insert Holding Method: Clamp | Compatible Insert Size Code: HG.-3; GRIP-3 |
| Shank Height (Decimal Inch): 0.7500 | Series: Heli-Grip |
| Shank Length (Decimal Inch): 4.0700 | Overall Length (Decimal Inch): 5.5000 |
| Multi-use Tool: No | Maximum Workpiece Diameter (Decimal Inch): 1.7600 |
| Back of Bar to Cutting Edge (Decimal Inch): 0.7000 | Head Length (Decimal Inch): 1.4300 |
| Primary Workpiece Material: Universal | UNSPSC Code: 23153308 |
| Primary Workpiece Material Code: P; S; H; K; M; N | Coolant Through: No |
| Country of Origin: Israel | |
| Toolholder Type: External Grooving | |
| Hand of Holder: Right Hand | |
| Minimum Groove Width (Decimal Inch): 0.1180 | |
| Toolholder Style: HELI | |
| Maximum Groove Width (Decimal Inch): 0.1250 | |
| Maximum Groove Width (Inch): 1/8 | |
| Insert Holding Method: Clamp | |
| Compatible Insert Size Code: HG.-3; GRIP-3 | |
| Shank Height (Decimal Inch): 0.7500 | |
| Series: Heli-Grip | |
| Shank Length (Decimal Inch): 4.0700 | |
| Overall Length (Decimal Inch): 5.5000 | |
| Multi-use Tool: No | |
| Maximum Workpiece Diameter (Decimal Inch): 1.7600 | |
| Back of Bar to Cutting Edge (Decimal Inch): 0.7000 | |
| Head Length (Decimal Inch): 1.4300 | |
| Primary Workpiece Material: Universal | |
| UNSPSC Code: 23153308 | |
| Primary Workpiece Material Code: P; S; H; K; M; N | |
| Coolant Through: No | |
| Country of Origin: Israel |
| MSC# | 52720026 |
| Mfr# | 2500526 |
