Indexable Slotting Cutter: 0.0490″ Cutting Width, 3.9400″ Cutter Dia, Arbor Connection, 1.1800″ Depth of Cut, 1.0000″ Hole Dia, 1.0000″ Shank Dia
Original price was: 1 308,00 $.140,89 $Current price is: 140,89 $.
Specifications
| Connection Type: Arbor | Maximum Depth of Cut (Decimal Inch): 1.1800 |
| Hole Diameter (Inch): 1 | Hole Diameter (Decimal Inch): 1.0000 |
| Cutter Diameter (Decimal Inch): 3.9400 | Shank Diameter (Inch): 1 |
| Shank Diameter (Decimal Inch): 1.0000 | Insert Holding Method: Self Clamping |
| Number Of Cutter Inserts: 10 | Compatible Insert Style: GSFN |
| Compatible Insert Size Code: 1.6 | Series: SGSF |
| Toolholder Style: SGSF | Hub Diameter (Decimal Inch): 1.5400 |
| Maximum RPM: 800 | Tool Application: Milling |
| Minimum Cutting Width (Decimal Inch): 0.0600 | Maximum Cutting Width (Decimal Inch): 0.0700 |
| Minimum Cutting Diameter (mm): 100.08 | Radius: No |
| Lead Angle: 90 | UNSPSC Code: 23241629 |
| Cutter Body Width (Decimal Inch): 0.0500 | Manufacturers Catalog Number: SGSF 100-1.6-1.000A |
| Number Of Teeth: 10 | Complete Insert Compatibility: GSFN 1.6 |
| Country of Origin: Israel | |
| Connection Type: Arbor | |
| Maximum Depth of Cut (Decimal Inch): 1.1800 | |
| Hole Diameter (Inch): 1 | |
| Hole Diameter (Decimal Inch): 1.0000 | |
| Cutter Diameter (Decimal Inch): 3.9400 | |
| Shank Diameter (Inch): 1 | |
| Shank Diameter (Decimal Inch): 1.0000 | |
| Insert Holding Method: Self Clamping | |
| Number Of Cutter Inserts: 10 | |
| Compatible Insert Style: GSFN | |
| Compatible Insert Size Code: 1.6 | |
| Series: SGSF | |
| Toolholder Style: SGSF | |
| Hub Diameter (Decimal Inch): 1.5400 | |
| Maximum RPM: 800 | |
| Tool Application: Milling | |
| Minimum Cutting Width (Decimal Inch): 0.0600 | |
| Maximum Cutting Width (Decimal Inch): 0.0700 | |
| Minimum Cutting Diameter (mm): 100.08 | |
| Radius: No | |
| Lead Angle: 90 | |
| UNSPSC Code: 23241629 | |
| Cutter Body Width (Decimal Inch): 0.0500 | |
| Manufacturers Catalog Number: SGSF 100-1.6-1.000A | |
| Number Of Teeth: 10 | |
| Complete Insert Compatibility: GSFN 1.6 | |
| Country of Origin: Israel |
| MSC# | 60823002 |
| Mfr# | 2300965 |
