Indexable Square-Shoulder End Mill: 150E14W125Z3L300C12, 1-1/2″ Cut Dia, 2.13″ Max Depth of Cut, 1-1/4″ Dia Weldon Flat Shank
136,89 $
Specifications
| Cutting Diameter (Decimal Inch): 1.5000 in | Cutting Diameter: 1-1/2 |
| Overall Length (Decimal Inch): 5.3000 | Maximum Depth of Cut (Decimal Inch): 2.1300 |
| Cutter Style: Mill 1-14 | Shank Type: Weldon Flat |
| Shank Diameter (Decimal Inch): 1.2500 | Shank Diameter (Inch): 1-1/4 |
| Insert Holding Method: Screw | Lead Angle: 0 |
| Head Length (Decimal Inch): 3.0000 | Maximum RPM: 28400 |
| Tool Application: Helical | Coolant Hole Diameter (Decimal Inch): 0.0790 |
| Insert Compatibility: EP14..; EC14.. | ISO Number: 150E14W125Z3L300C12 |
| UNSPSC Code: 27112803 | Number Of Flutes: 3 |
| Number Of Cutter Inserts: 12 | Coolant Through: Yes |
| Country of Origin: Brazil | |
| Cutting Diameter (Decimal Inch): 1.5000 in | |
| Cutting Diameter: 1-1/2 | |
| Overall Length (Decimal Inch): 5.3000 | |
| Maximum Depth of Cut (Decimal Inch): 2.1300 | |
| Cutter Style: Mill 1-14 | |
| Shank Type: Weldon Flat | |
| Shank Diameter (Decimal Inch): 1.2500 | |
| Shank Diameter (Inch): 1-1/4 | |
| Insert Holding Method: Screw | |
| Lead Angle: 0 | |
| Head Length (Decimal Inch): 3.0000 | |
| Maximum RPM: 28400 | |
| Tool Application: Helical | |
| Coolant Hole Diameter (Decimal Inch): 0.0790 | |
| Insert Compatibility: EP14..; EC14.. | |
| ISO Number: 150E14W125Z3L300C12 | |
| UNSPSC Code: 27112803 | |
| Number Of Flutes: 3 | |
| Number Of Cutter Inserts: 12 | |
| Coolant Through: Yes | |
| Country of Origin: Brazil |
| MSC# | 63220693 |
| Mfr# | 3732892 |
