Sale!
Indexable Threading Toolholder: Internal, Right Hand, 14.3 x 5/8″ Shank
Original price was: 281,00 $.128,89 $Current price is: 128,89 $.
Specifications
| Thread Type: Internal | Hand of Holder: Right Hand |
| Shank Width/Diameter (Decimal Inch): 0.6250 | Shank Width/Diameter (Inch): 5/8 |
| Toolholder Style: R166.0L | Insert Compatibility: R166.0L to 11UN01 to 160; R166.0L to 11UN01 to 240; R166.0L to 11NT01F180; R166.0L to 11UN01 to 140; R166.0L to 11UN01 to 280; R166.0L to 11NT01F140; R166.0L to 11UN01 to 180; R166.0L to 11MM01 to 150; R166.0L to 11MM01 to 050; R166.0L to 11UN01 to 200; R166.0L to 11UN01 to 320; R166.0L to 11MM01 to 200; R166.0L to 11MM01 to 100 |
| Insert Holding Method: Screw | Shank Height (mm): 14.30 |
| Shank Height (Decimal Inch): 0.5630 | Shank Length (Decimal Inch): 5.1669 |
| Overall Length (Inch): 6 | Overall Length (Decimal Inch): 6.0000 |
| Minimum Bore Diameter (Decimal Inch): 0.6300 | Minimum Bore Diameter (mm): 16.00 |
| Multi-use Tool: Yes | Cutting Tool Application: Threading |
| Head Length (Decimal Inch): 1.0300 | Maximum Depth of Cut (Decimal Inch): 1.8750 |
| Center to Cutting Edge (Decimal Inch): 0.4130 | Insert Inscribed Circle (Decimal Inch): 0.2500 |
| Insert Inscribed Circle (Inch): 1/4 | Neck Diameter (Decimal Inch): 0.6250 |
| Pitch Range: 32 to 12 | UNSPSC Code: 23291800 |
| Toolholder Material: Steel | Coolant Through: No |
| Series: T-Max U-Lock 166 | Country of Origin: India |
| Thread Type: Internal | |
| Hand of Holder: Right Hand | |
| Shank Width/Diameter (Decimal Inch): 0.6250 | |
| Shank Width/Diameter (Inch): 5/8 | |
| Toolholder Style: R166.0L | |
| Insert Compatibility: R166.0L to 11UN01 to 160; R166.0L to 11UN01 to 240; R166.0L to 11NT01F180; R166.0L to 11UN01 to 140; R166.0L to 11UN01 to 280; R166.0L to 11NT01F140; R166.0L to 11UN01 to 180; R166.0L to 11MM01 to 150; R166.0L to 11MM01 to 050; R166.0L to 11UN01 to 200; R166.0L to 11UN01 to 320; R166.0L to 11MM01 to 200; R166.0L to 11MM01 to 100 | |
| Insert Holding Method: Screw | |
| Shank Height (mm): 14.30 | |
| Shank Height (Decimal Inch): 0.5630 | |
| Shank Length (Decimal Inch): 5.1669 | |
| Overall Length (Inch): 6 | |
| Overall Length (Decimal Inch): 6.0000 | |
| Minimum Bore Diameter (Decimal Inch): 0.6300 | |
| Minimum Bore Diameter (mm): 16.00 | |
| Multi-use Tool: Yes | |
| Cutting Tool Application: Threading | |
| Head Length (Decimal Inch): 1.0300 | |
| Maximum Depth of Cut (Decimal Inch): 1.8750 | |
| Center to Cutting Edge (Decimal Inch): 0.4130 | |
| Insert Inscribed Circle (Decimal Inch): 0.2500 | |
| Insert Inscribed Circle (Inch): 1/4 | |
| Neck Diameter (Decimal Inch): 0.6250 | |
| Pitch Range: 32 to 12 | |
| UNSPSC Code: 23291800 | |
| Toolholder Material: Steel | |
| Coolant Through: No | |
| Series: T-Max U-Lock 166 | |
| Country of Origin: India |
| MSC# | 49379068 |
| Mfr# | 5742014 |
