Indexable Threading Toolholder: Internal, Right Hand, 25.4 x 1″ Shank
Original price was: 412,00 $.128,99 $Current price is: 128,99 $.
Specifications
| Thread Type: Internal | Hand of Holder: Right Hand |
| Shank Width/Diameter (Decimal Inch): 1.0000 | Shank Width/Diameter (Inch): 1 |
| Toolholder Style: 266.RL | Insert Compatibility: 266RL to 16AC01F160E; 266RL to 16AC01F140E; 266RL to 16MM01A125M; 266RL to 16AC01F120E; 266RL to 16AC01F100E; 266RL to 16MM01A300M; 266RL to 16MM01A100M; 266RL to 16MM01A200M; 266RL to 16MM01A075M; 266RL to 16MM01A250M; 266RL to 16MM01A175M; 266RL to 16MM01A150M; 266RL to 16AC01F080E; 266RL to 16MM01A050M |
| Insert Holding Method: Screw | Shank Height (mm): 25.40 |
| Shank Length (Decimal Inch): 10.6591 | Overall Length (Inch): 12 |
| Overall Length (Decimal Inch): 12.0000 | Minimum Bore Diameter (Decimal Inch): 1.2600 |
| Multi-use Tool: Yes | Cutting Tool Application: Grooving; Threading |
| Head Length (Decimal Inch): 1.3410 | Maximum Depth of Cut (Decimal Inch): 3.0000 |
| Center to Cutting Edge (mm): 16.99 | Center to Cutting Edge (Decimal Inch): 0.6690 |
| Insert Inscribed Circle (Decimal Inch): 0.5000 | Insert Inscribed Circle (Inch): 1/2 |
| Neck Diameter (Decimal Inch): 1.0000 | Pitch Range: 8 to 4 |
| UNSPSC Code: 23291800 | Toolholder Material: Steel |
| Coolant Through: Yes | Series: CoroThread 266 |
| Country of Origin: India | |
| Thread Type: Internal | |
| Hand of Holder: Right Hand | |
| Shank Width/Diameter (Decimal Inch): 1.0000 | |
| Shank Width/Diameter (Inch): 1 | |
| Toolholder Style: 266.RL | |
| Insert Compatibility: 266RL to 16AC01F160E; 266RL to 16AC01F140E; 266RL to 16MM01A125M; 266RL to 16AC01F120E; 266RL to 16AC01F100E; 266RL to 16MM01A300M; 266RL to 16MM01A100M; 266RL to 16MM01A200M; 266RL to 16MM01A075M; 266RL to 16MM01A250M; 266RL to 16MM01A175M; 266RL to 16MM01A150M; 266RL to 16AC01F080E; 266RL to 16MM01A050M | |
| Insert Holding Method: Screw | |
| Shank Height (mm): 25.40 | |
| Shank Length (Decimal Inch): 10.6591 | |
| Overall Length (Inch): 12 | |
| Overall Length (Decimal Inch): 12.0000 | |
| Minimum Bore Diameter (Decimal Inch): 1.2600 | |
| Multi-use Tool: Yes | |
| Cutting Tool Application: Grooving; Threading | |
| Head Length (Decimal Inch): 1.3410 | |
| Maximum Depth of Cut (Decimal Inch): 3.0000 | |
| Center to Cutting Edge (mm): 16.99 | |
| Center to Cutting Edge (Decimal Inch): 0.6690 | |
| Insert Inscribed Circle (Decimal Inch): 0.5000 | |
| Insert Inscribed Circle (Inch): 1/2 | |
| Neck Diameter (Decimal Inch): 1.0000 | |
| Pitch Range: 8 to 4 | |
| UNSPSC Code: 23291800 | |
| Toolholder Material: Steel | |
| Coolant Through: Yes | |
| Series: CoroThread 266 | |
| Country of Origin: India |
| MSC# | 03413762 |
| Mfr# | 5758094 |
