Indexable Turning Toolholder: Screw

112,99 $

SKU: SKUPyywqAcPqr Categories: Indexable Cutting Tools, Indexable Turning & Boring, Shop All Products Tag: Sandvik Coromant Brand: Sandvik Coromant

Description
Reviews (0)

Specifications

Toolholder Style: SCLCR	Hand of Holder: Right Hand
Insert Compatibility: CCMT 32.52	Insert Holding Method: Screw
Shank Width (Inch): 5/8	Shank Height (Inch): 5/8
Overall Length (Decimal Inch): 5.0000	Shank Width (mm): 15.88
Shank Height (mm): 15.88	Rake: Neutral
Rake Angle: 0	Multi-use Tool: Yes
Shank Width (Decimal Inch): 0.6250	Shank Height (Decimal Inch): 0.6250
Series: CoroTurn® 107	Overall Length (Inch): 5
Cutting Tool Application: Facing	Head Length (Decimal Inch): 0.6250
Head Length (mm): 15.88	Back of Bar to Cutting Edge (Inch): 5
Back of Bar to Cutting Edge (Decimal Inch): 5.0000	Back of Bar to Cutting Edge (mm): 127.00
Insert Inscribed Circle (Decimal Inch): 0.3750	Insert Inscribed Circle (Inch): 3/8
Insert Width (Inch): 3/8	Insert Width (Decimal Inch): 0.3750
Toolholder Material: Steel	UNSPSC Code: 23153308
Country of Origin: India
Toolholder Style: SCLCR
Hand of Holder: Right Hand
Insert Compatibility: CCMT 32.52
Insert Holding Method: Screw
Shank Width (Inch): 5/8
Shank Height (Inch): 5/8
Overall Length (Decimal Inch): 5.0000
Shank Width (mm): 15.88
Shank Height (mm): 15.88
Rake: Neutral
Rake Angle: 0
Multi-use Tool: Yes
Shank Width (Decimal Inch): 0.6250
Shank Height (Decimal Inch): 0.6250
Series: CoroTurn® 107
Overall Length (Inch): 5
Cutting Tool Application: Facing
Head Length (Decimal Inch): 0.6250
Head Length (mm): 15.88
Back of Bar to Cutting Edge (Inch): 5
Back of Bar to Cutting Edge (Decimal Inch): 5.0000
Back of Bar to Cutting Edge (mm): 127.00
Insert Inscribed Circle (Decimal Inch): 0.3750
Insert Inscribed Circle (Inch): 3/8
Insert Width (Inch): 3/8
Insert Width (Decimal Inch): 0.3750
Toolholder Material: Steel
UNSPSC Code: 23153308
Country of Origin: India
