Indexable Turning Toolholder: Wedge

Original price was: 182,00 $.Current price is: 121,99 $.

SKU: SKUBUxJzOIf4f Categories: Indexable Cutting Tools, Indexable Turning & Boring, Shop All Products Tag: Sandvik Coromant Brand: Sandvik Coromant

Description
Reviews (0)

Specifications

Toolholder Style: DDPNN	Hand of Holder: Neutral
Insert Compatibility: DNMG 432	Insert Holding Method: Wedge
Shank Width (Inch): 1	Shank Height (Inch): 1
Overall Length (Decimal Inch): 6.0000	Shank Width (mm): 25.40
Shank Height (mm): 25.40	Rake: Negative
Rake Angle: -5	Multi-use Tool: Yes
Shank Width (Decimal Inch): 1.0000	Shank Height (Decimal Inch): 1.0000
Series: T-Max® P	Overall Length (Inch): 6
Cutting Tool Application: Facing	Head Length (Decimal Inch): 1.6100
Head Length (mm): 40.89	Back of Bar to Cutting Edge (Inch): 6
Back of Bar to Cutting Edge (Decimal Inch): 6.0000	Back of Bar to Cutting Edge (mm): 152.40
Insert Inscribed Circle (Decimal Inch): 0.5000	Insert Inscribed Circle (Inch): 1/2
Insert Width (Inch): 1/2	Insert Width (Decimal Inch): 0.5000
Toolholder Material: Steel	UNSPSC Code: 23153308
Country of Origin: India
Toolholder Style: DDPNN
Hand of Holder: Neutral
Insert Compatibility: DNMG 432
Insert Holding Method: Wedge
Shank Width (Inch): 1
Shank Height (Inch): 1
Overall Length (Decimal Inch): 6.0000
Shank Width (mm): 25.40
Shank Height (mm): 25.40
Rake: Negative
Rake Angle: -5
Multi-use Tool: Yes
Shank Width (Decimal Inch): 1.0000
Shank Height (Decimal Inch): 1.0000
Series: T-Max® P
Overall Length (Inch): 6
Cutting Tool Application: Facing
Head Length (Decimal Inch): 1.6100
Head Length (mm): 40.89
Back of Bar to Cutting Edge (Inch): 6
Back of Bar to Cutting Edge (Decimal Inch): 6.0000
Back of Bar to Cutting Edge (mm): 152.40
Insert Inscribed Circle (Decimal Inch): 0.5000
Insert Inscribed Circle (Inch): 1/2
Insert Width (Inch): 1/2
Insert Width (Decimal Inch): 0.5000
Toolholder Material: Steel
UNSPSC Code: 23153308
Country of Origin: India
