Spade Drill: 1-1/2 to 2-3/8" Dia, 8-1/2" Max Depth, Straight Flute

Spade Drill: 1-1/2 to 2-3/8″ Dia, 8-1/2″ Max Depth, Straight Flute

130,89 $

SKU: SKUR4SHl3cI6L Categories: Indexable Cutting Tools, Indexable Holemaking, Shop All Products Tag: Allied Machine And Engineering Brand: Allied Machine And Engineering

Description
Reviews (0)

Specifications

Minimum Drill Diameter (Inch): 1-1/2	Maximum Drill Diameter (Inch): 2-3/8
Maximum Drill Depth (Inch): 8-1/2	Spade Drill Length: Standard
Shank Type: Taper	Shank Taper Size: 4MT
Shank Diameter (Decimal Inch): 1.2310	Length Type: Standard
Tool Material: Steel	Overall Length (Inch): 15-1/16
Coolant Entry Style Code: 2-Radial Entry	Series: HP-C
Flute Type: Straight	Flute Length (Inch): 8-1/2
Body Length (Inch): 11-7/16	Shank Length (Inch): 4-7/8
Tool Performance: High Performance	Coolant Hole Thread Size: 1/4
Coolant Hole Thread Type: NPT	Primary Workpiece Material: Universal
Primary Workpiece Material Code: P; K; M; N	Rotary Coolant Adapter Compatibility: 2T-4SR
Coolant Through: Yes	UNSPSC Code: 23241600
Country of Origin: UNITED STATES
Minimum Drill Diameter (Inch): 1-1/2
Maximum Drill Diameter (Inch): 2-3/8
Maximum Drill Depth (Inch): 8-1/2
Spade Drill Length: Standard
Shank Type: Taper
Shank Taper Size: 4MT
Shank Diameter (Decimal Inch): 1.2310
Length Type: Standard
Tool Material: Steel
Overall Length (Inch): 15-1/16
Coolant Entry Style Code: 2-Radial Entry
Series: HP-C
Flute Type: Straight
Flute Length (Inch): 8-1/2
Body Length (Inch): 11-7/16
Shank Length (Inch): 4-7/8
Tool Performance: High Performance
Coolant Hole Thread Size: 1/4
Coolant Hole Thread Type: NPT
Primary Workpiece Material: Universal
Primary Workpiece Material Code: P; K; M; N
Rotary Coolant Adapter Compatibility: 2T-4SR
Coolant Through: Yes
UNSPSC Code: 23241600
Country of Origin: UNITED STATES
